Easy cleaning and high corrosion resistance
Continuous welding seams completely free of impurities. Open fork, sanitisable design that prevents the accumulation of product residues and allows the equipment to be thoroughly cleaned.
Hand Pallet Truck Scale
MPT10S
The innovative and patented hygienic design of the new Inoxtruck hand pallet truck ensures a reduced risk of contamination microbiological contamination, guaranteeing strict hygiene compliance in the high-demand area of the food industry. The MPTS series of hand pallet trucks provides accurate weight measurement for incoming and outgoing goods, thanks to its 4 weigh cells made of AISI 316L stainless steel with IP68 protection. The Integrated Weighing System incorporates a weighing structure mounted inside the pallet truck chassis itself, eliminating direct impacts on the weighing structure and minimising the need to calibrate the load cells.
- No lubrication
- Without lifting chains
- Sealed bearings
- Sanitisable design
Technical characteristics
Product
Hand Pallet Truck Scale
Manufacturer model
MPT10S
Height
120 mm
Load
1000 - 1500 kg.
Downloadables
Key features
Ergonomic
The ergonomic design of the tiller and its 210° angle allow the operator to handle it easily and reduce the efforts in the lifting and travel phase. Controls for the three tiller positions (lowering, neutral, lifting) allow safe control of the forks.
100% stainless steel
Made entirely of 304L or 316L stainless steel, including hydraulic equipment.
Minimum maintenance
All bearings are sealed and lubricated as standard. The joints of the Inoxtruck pallet truck are fitted with polymer bearings that do not require lubrication. In addition, the stainless steel braided cable to operate the valve is plastic coated.
Electronic protection
The Inoxtruck pallet truck weigher features advanced electronic protection to ensure durability and accuracy in demanding environments. Its load cells are protected to IP68 standard, while the display has IP65 protection, guaranteeing resistance to water, dust and adverse conditions.
Videos and images
Food Industry
